Profile positio/velocity/homing mode, Cyclic sync position/velocity/torque mode, Clock direction mode
Protective functions
Over current, Over/Under Voltage, Overheating, Supply inversion
Protection Class
IP20
Pollution degree
2
Operating Temperature
+5 / +40°C
Humidity
5 - 85%
Digital Inputs
4
Digital Outputs
2
Analog Inputs
2
Encoder Inputs
Incremenal or Magnetic Absolute
Hall Input
5V Single-Ended (TTL/CMOS) hall sensors
Technical Files
Datasheet
3D STEP file
Short manual
All motors and servomtors with Phase Current up to 12A rms.
Custom combinations are available on request. Contact us
DL Studio
DL Studio is a PC Window program that allows the configuration and debugging of all stepper and brushless motor and drives. Easy and intuitive, DL Studio allows users to configure of all the main operating parameters through guided procedures, real-time monitoring of all the operating parameters and allowing access to the alarm history memory.
With DL Studio it is possible to create configuration profiles and save them to your PC to be downloaded in each new drive depending on the needs of the application. In addition, it also allows you to update the firmware version of our drives.
Software
Manual
Service SCI Interface cable is required for programming and available on request.
